In cooperation with Swedish door manufacturer HIAK, Vibratec can offer sound insulating doors, both single and double leafs, in wood or in steel. We can supply from a standard range or offer a custom design door solution, with up to 56 dB(A) noise reduction.
Door leaf
Massive leaf with special design for maximum sound reduction.
Frame
Frame in pine as standard but can be delivered in many kinds of wood.
Weight
Door, about 45kg/m2.
Door fire classed, approximately 55kg/m2.
Locks
Delivered as standard with ASSA 565/410, but can be delivered with almost any type of locks.
Options
Electric locks, magnetic contacts, electric strikes, cable entry, cylinders, clamp protection.
Designation
Single door TLE (Rw = 47)
Double door TLD (Rw = 47)
Single door TLE—48 (Rw = 48)
Double door TLD-48 (Rw = 48)
Type of thresholds see chart
Window
The doors can be delivered with windows with the same acoustic performance as the doors.
Door closer
Door closer may only be installed on the hinge side. ASSA DC300 or GEZE TS4000 is standard. But can be delivered with other closers too.
Emergency exit
The door can be delivered with panic bars or handle type Assa 179B
Fire doors
The doors can be delivered classified to EI230, Sa, S200 Max size for single door 12x23M, Double door 22x23M
Surface door leaf:
Standard is painted white color (NCS S 0502-Y) but it can be painted in almost any NCS or RAL color. Different types of plastic laminates and veneers are also possible.
