Series of all-metal mounts with equifrequency characteristics for the defined load range, capable of high tensile loads.
cast iron upper cup and base
cast iron shaft
all-metal cushion (18/8 stainless steel)
protection: paint and cast iron parts
weight
V 118 – MG : 2,4 kg (approx.)
V 318 : 10 kg (approx.)
Characteristics
Resonance frequencies:
axial : 18 to 25 Hz
radial : 18 to 25 Hz
Maximum sinusoidal input amplitude: ± 0,3 mm
Amplification factor at resonance: < 6
Operational temperature: -70oC to +300oC
Ultimate strength: see table
Applications
suspension of machine-tools: grinding machines, crushing machines, fly-presses, priting machines, textile machinery
suspention of rotating machines: engines, pumps, etc, rotating over 2500 rpm
suspension of overhead conveyours, metal structures, cabins equipment
marine: suspension of engines, exhaust pipes, manifold, etc.
